Total Flooding Clean Agent Fire Suppression Systems
Engineered Room and Hazard Protection: Fast, Clean, and Built for Critical Assets.
Orbis® Total Flooding Systems are engineered to protect enclosed rooms and critical hazards through rapid clean agent discharge across the entire protected volume. Designed for data centers, electrical rooms, archives, and special hazards, the system helps suppress fire quickly while minimizing residue, downtime, and equipment damage.
- Compatible with FK-5-1-12, HFC-227ea, CO2
- Available in 147L to 369L cylinder capacities
- 25 bar nitrogen-superpressurized cylinders
- Supports manual, pneumatic, and electrical release
- Suitable for single or multi-cylinder systems
- Clean agent discharge with no residue
- Suitable for sensitive electronics and critical equipment
- Rapid room-wide fire suppression
- Helps minimize business interruption and asset loss
- Flexible actuation and monitoring options
- Available for multiple hazard sizes and configurations
- Designed for full-room or enclosure flooding applications
- Compatible with FK-5-1-12 and HFC-227ea clean agents
- Pressurized cylinder assemblies with discharge valves and gauges
- Engineered nozzle and piping distribution
- Manual, pneumatic, and electrical actuation options
- Monitoring accessories available for supervisory feedback and status indication
System Configuration
Agent Compatibility
Cylinder Assemblies
Piping & Discharge Network
System Configuration
- Engineered total flooding clean agent suppression system
- Designed for full-room volumetric discharge
- Supports single-cylinder, multi-cylinder, and manifolded systems
- Available in multiple cylinder capacities
- Suitable for single-zone or multi-zone hazard protection
- Compatible with selector valve and directional valve arrangements
Agent Compatibility
- Compatible with FK-5-1-12
- Compatible with HFC-227ea
- Compatible with CO2
- Agent quantity based on hazard volume and required design concentration
- Concentration adjusted for temperature and altitude correction factors
- Suitable for normally occupied and non-occupied spaces depending on agent and design basis
Cylinder Assemblies
- Available cylinder capacities: 147L, 180L, 270L, and 369L
- Superpressurized with dry nitrogen to 25 bar at 21°C
- Manufactured to recognized DOT cylinder standards
- Equipped with integrated pressure gauge and discharge valve
- Optional liquid level indication on larger cylinders
Piping & Discharge Network
- Engineered hydraulic flow calculation piping layouts
- Precision nozzle orifice sizing
- Brass and specialty clean agent discharge nozzles
- Configurable pipe diameters, tee splits, and nozzle zoning
- Designed for uniform room concentration distribution
- Supports extended pipe runs for remote cylinder placement
